souffle::ast::ComponentType Class Reference

Component type of a component. More...

#include <ComponentType.h>

Inheritance diagram for souffle::ast::ComponentType:

Collaboration diagram for souffle::ast::ComponentType:

Public Member Functions
ComponentType *	clone () const override
	Create a clone (i.e. More...
	ComponentType (std::string name="", std::vector< QualifiedName > params={}, SrcLocation loc={})
const std::string &	getName () const
	Return component name. More...
const std::vector< QualifiedName > &	getTypeParameters () const
	Return component type parameters. More...
void	setName (std::string n)
	Set component name. More...
void	setTypeParameters (const std::vector< QualifiedName > &params)
	Set component type parameters. More...
Public Member Functions inherited from souffle::ast::Node
virtual void	apply (const NodeMapper &)
	Apply the mapper to all child nodes. More...
std::string	extloc () const
	Return source location of the syntactic element. More...
virtual std::vector< const Node * >	getChildNodes () const
	Obtain a list of all embedded AST child nodes. More...
const SrcLocation &	getSrcLoc () const
	Return source location of the Node. More...
	Node (SrcLocation loc={})
bool	operator!= (const Node &other) const
	Inequality check for two AST nodes. More...
bool	operator== (const Node &other) const
	Equivalence check for two AST nodes. More...
void	setSrcLoc (SrcLocation l)
	Set source location for the Node. More...
virtual	~Node ()=default

Protected Member Functions
bool	equal (const Node &node) const override
	Abstract equality check for two AST nodes. More...
void	print (std::ostream &os) const override
	Output to a given output stream. More...

Private Attributes
std::string	name
	Component name. More...
std::vector< QualifiedName >	typeParams
	Component type parameters. More...

Detailed Description

Component type of a component.

Example: name < Type1, Type2, ... > where name is the component name and < Type, Type, ... > is a list of component type parameters (either actual or formal).

Definition at line 45 of file ComponentType.h.

Constructor & Destructor Documentation

ComponentType()

souffle::ast::ComponentType::ComponentType ( std::string  name = "", std::vector< QualifiedName >  params = {}, SrcLocation  loc = {}  )

inline

Definition at line 47 of file ComponentType.h.

Member Function Documentation

clone()

ComponentType* souffle::ast::ComponentType::clone ( ) const

inlineoverridevirtual

Create a clone (i.e.

deep copy) of this node

Implements souffle::ast::Node.

Definition at line 70 of file ComponentType.h.

                                 {
            os << "<" << join(typeParams) << ">";

References souffle::join(), and typeParams.

Here is the call graph for this function:

equal()

bool souffle::ast::ComponentType::equal ( const Node &  ) const

inlineoverrideprotectedvirtual

Abstract equality check for two AST nodes.

Reimplemented from souffle::ast::Node.

Definition at line 82 of file ComponentType.h.

getName()

const std::string& souffle::ast::ComponentType::getName ( ) const

inline

Return component name.

Definition at line 51 of file ComponentType.h.

getTypeParameters()

const std::vector<QualifiedName>& souffle::ast::ComponentType::getTypeParameters ( ) const

inline

Return component type parameters.

Definition at line 61 of file ComponentType.h.

                                          {

print()

void souffle::ast::ComponentType::print ( std::ostream &  os ) const

inlineoverrideprotectedvirtual

Output to a given output stream.

Implements souffle::ast::Node.

Definition at line 75 of file ComponentType.h.

                                                {
        const auto& other = static_cast<const ComponentType&>(node);
        return name == other.name && typeParams == other.typeParams;
    }


References name, and typeParams.

setName()

void souffle::ast::ComponentType::setName ( std::string  n )

inline

Set component name.

Definition at line 56 of file ComponentType.h.

setTypeParameters()

void souffle::ast::ComponentType::setTypeParameters ( const std::vector< QualifiedName > &  params )

inline

Set component type parameters.

Definition at line 66 of file ComponentType.h.

         :
    void print(std::ostream& os) const override {

Field Documentation

name

std::string souffle::ast::ComponentType::name

private

Component name.

Definition at line 89 of file ComponentType.h.

Referenced by print().

typeParams

std::vector<QualifiedName> souffle::ast::ComponentType::typeParams

private

Component type parameters.

Definition at line 92 of file ComponentType.h.

Referenced by clone(), and print().

---

The documentation for this class was generated from the following file:

• ast/ComponentType.h
